DB Drive WDX 1000.1 1000W 1-Channel Amplifier 1 ohm stable
DB Drive WDX 1000.1 1000W 1-Channel Amplifier 1 ohm stable
Couldn't load pickup availability
20 in stock
Give your system dedicated amplifier power
Build your bass setup around the DB Drive WDX 1000.1 1000W 1-Channel Amplifier 1 ohm stable. This mono amplifier gives your compatible subwoofer system a dedicated source of power.
Key details
- Model / SKU: WDX 1000.1
- Frequency Response 20Hz ~ 300Hz
Fitment & system matching
Match RMS output at the final wired impedance to your speakers or subwoofers. Check minimum impedance, mounting dimensions, fuse requirements and power-wire size. Peak/MAX ratings are not continuous RMS output.
Full product details & specifications
Features:
CLASS “D” CIRCUITRY
Direct Connect Speaker Terminals
4 Gauge Power Wire Input
CHM- Collective Heat Management
ACT – Adaptive Crossover Technology
SESI – Signal Evaluation Status Indicator
APC – Audio Protection Circuit
Included Remote Level Control
Length: 9" Width: 5.50" Height: 2.38"
GENERAL SPECIFICATIONS
Rated Power @ 14.4 Volts
1 x 1000 Watts @ 1Ω
1 x 500 Watts @ 2Ω
1 x 250 Watts @ 4Ω
PARAMETERS
Frequency Response 20Hz ~ 300Hz
S/N Ratio < 95 dB
Low Level Input 6V – 0.2V
Variable High Pass Filter (12DB Slope) 40Hz ~ 300Hz
Variable Low Pass Filter (12DB Slope) 10Hz ~ 40Hz
Bass Equalizer 0dB – 9dB
Working Voltage 12-15 Volts
