• DB Drive WDX6.5G1.4 6.5" Dual 4-Ohm Subwoofer
1 5

DB Drive WDX6.5G1.4 6.5" Dual 4-Ohm Subwoofer

DB Drive WDX6.5G1.4 6.5" Dual 4-Ohm Subwoofer

$199.00 USD
$199.00 USD
Sale Sold out

20 in stock

Add a dedicated foundation for bass

Build your low end around the DB Drive WDX6.5G1.4 6.5" Dual 4-Ohm Subwoofer. Pair it with a correctly sized enclosure and compatible amplifier for a bass system tailored to your vehicle and listening goals.

Key details

  • Model / SKU: WDX6.5G1.4
  • Dual voice coils: choose the correct impedance option and plan the final amplifier load before wiring.
  • Mounting Depth (C) 5.94″ (151mm)

Fitment & system matching

Match voice-coil configuration and final wired impedance to your amplifier. Check RMS power handling, mounting depth and recommended enclosure volume. Peak/MAX power is not continuous RMS power.

Full product details & specifications
Designed for true bass enthusiasts, the WDX6.5G2R.4 subwoofers offer unmatched power and precision. • Featuring a custom mounting gasket for a perfect seal, eliminating rear-canceling waves for pure bass. • All-new dust caps and a custom-tooled aluminum basket provide durability, rigidity, and optimal heat dissipation. • The custom ribbed surround and High Excursion motor with Y35 ferrite magnets and high-temperature voice coils deliver deep, distortion-free bass. • Built for Bass: Power handling up to 1500 watts dynamic (750 watts nominal) • The WDX6.5G2R.4 sets a new standard for earth-shaking bass. Ready to feel the difference?



Our engineers at DB Drive have designed this subwoofer from the ground up to shake the ground up. The double-stitched foam surround and die-cast aluminum vented basket allow for maximum excursion, while the protective magnet cover gives the woofer a rugged yet stylish appearance.
1.5" BASV High-Temperature Voice coil

  • Non-pressed paper cone
  • Double stitched foam surround
  • Dual poly-cotton dampeners
  • Die-cast aluminum vented basket
  • Rubber gasket trim ring
  • Large gauge compression terminals
  • Protective magnet cover

Outside Diameter (A)    7.14″ (181.35mm)
Cutout Diameter (B)    4.60″ (116.84mm)
Mounting Depth (C)    5.94″ (151mm)
GENERAL SPECIFICATIONS
Structure    6.5″ (16.51cm) Woofer
Dynamic Power Handling    600 Watts
Nominal Power Handling    300 Watts
Impedance    Dual 4Ω Voice Coil
PARAMETERS
Resonant Frequency (fs)    58.94Hz
D.C. Voice Coil Resistance (Re)    3.2 x 3.2Ω
Mechanical Quality Factor (Qms)    4.065
Electrical Quality Factor (Qes)    0.823
Total Quality Factor (Qts)    0.684
Equivalent Air Volume to Cms (Vas)    2.749 L
Mass of Diaphragm/Coil (Mms)    77.157 g
Force Factor (Bl)    7.453
Sound Pressure Level (SPL)    80.2 dB

Need help choosing? Explore our installation services before planning your build.
