DS18 G1800.1D Class D Full Range 1800W 1-channel Amplifier
DS18 G1800.1D Class D Full Range 1800W 1-channel Amplifier
Regular price
$239.95 USD
Regular price
Sale price
$239.95 USD
Quantity
Couldn't load pickup availability
20 in stock
Give your system dedicated amplifier power
Build your bass setup around the DS18 G1800.1D Class D Full Range 1800W 1-channel Amplifier. This mono amplifier gives your compatible subwoofer system a dedicated source of power.
Key details
- Model / SKU: G1800.1D
- RMS Wattage: 600 Watts RMS @ 1 ohm, 400 Watts RMS @ 2 ohms, 250 Watts RMS @ 4 ohms
- Frequency Response: 10-500Hz
Fitment & system matching
Match RMS output at the final wired impedance to your speakers or subwoofers. Check minimum impedance, mounting dimensions, fuse requirements and power-wire size. Peak/MAX ratings are not continuous RMS output.
Full product details & specifications
Key Features
- Digital Class D Subwoofer Monoblock Amplifier
- MAX Wattage: 1800w Peak
- RMS Wattage: 600 Watts RMS @ 1 ohm, 400 Watts RMS @ 2 ohms, 250 Watts RMS @ 4 ohms
- Frequency Response: 10-500Hz
- Signal to Noise Ratio: >93dB
- Efficiency at 4 ohms: 90%
- Total Harmonic Distortion: 0.001%
- Input Range: .25-6v
- Selectable X-over: LPF Fixed
- Bass Boost- 0-12dB
- Phase: 0-180
- Power and Ground Terminal: 4 GA
- Minimum Impedance: 1 ohm
- Dimensions: 9.64"L x 4.72" W x1.96"H
Need help choosing? Explore our installation services before planning your build.
