DS18 G1800.4D Class D Full Range 1800W 4-channel Amplifier
DS18 G1800.4D Class D Full Range 1800W 4-channel Amplifier
Regular price
$287.95 USD
Regular price
Sale price
$287.95 USD
Quantity
Couldn't load pickup availability
20 in stock
Give your system dedicated amplifier power
The DS18 G1800.4D Class D Full Range 1800W 4-channel Amplifier gives you four channels of amplification for a multi-speaker system. Match its output at your chosen impedance to the speakers you plan to run.
Key details
- Model / SKU: G1800.4D
- RMS Wattage: 2x430 Watts RMS @ 4 ohm bridge, 4x230 Watts RMS @ 2 ohms, 4x150 Watts RMS @ 4 ohms
- Frequency Response: 20-20KHz
Fitment & system matching
Match RMS output at the final wired impedance to your speakers or subwoofers. Check minimum impedance, mounting dimensions, fuse requirements and power-wire size. Peak/MAX ratings are not continuous RMS output.
Full product details & specifications
Key Features
- Digital Class D 4 Channel Amplifier
- MAX Wattage: 1800w Peak
- RMS Wattage: 2x430 Watts RMS @ 4 ohm bridge, 4x230 Watts RMS @ 2 ohms, 4x150 Watts RMS @ 4 ohms
- Frequency Response: 20-20KHz
- Signal to Noise Ratio: >90dB
- Efficiency at 4 ohms: 81%
- Total Harmonic Distortion: 0.01%
- Input Range: .25-6v
- Selectable X-over: LPF, HPF. Flat
- Phase: 0-180
- Power and Ground Terminal: 4 GA
- Minimum Impedance: 2 ohm
- Dimensions: 10.43"L x4.72"W x 1.96"H
Need help choosing? Explore our installation services before planning your build.
