JVC KWM590BT Double-Din Mechless Receiver, BT, Carplay/Android Auto

Digital Media Receiver featuring 6.8" Capacitive Touch Monitor / Apple CarPlay® / Android Auto™ / USB Mirroring / Bluetooth® / 13-Band EQ / Short Chassis

Monitor
Screen Size
6.8"W SVGA
Touch Panel
Capacitive
Customizable GUI
Yes
Key Illumination Color
Blue
Dimmer
Yes
Multilingual Display
Yes[4]
Media Playback
MP3 Compatible with Tag
USB
WMA Compatible with Tag
USB
WAV Compatible with Tag
USB
AAC Compatible with Tag
USB
FLAC Compatible with Tag
USB
H.264 Compatible
USB
WMV Compatible
USB
MPEG 1/2 Compatible
USB
MPEG 4 Compatible
USB
MKV Compatible
USB
Bluetooth Control
Built-in Bluetooth[1]
Yes (Hands-Free MIC Built-in)
Hands Free Call
Yes (HFP1.8 Wideband Speech)
Audio Streaming & Control (A2DP, AVRCP)
Yes
Supported Audio Formats
AAC / SBC
Voice Dialing (voice recognition compatible mobile phone required)
Yes
Phone Book Access Profile (PBAP)
Yes
Auto Pairing for iPhone/Android
Yes
Android Control
Android Auto[2]
Yes (via USB)
Mirroring for Android
Yes (via USB) *Need mirroring App
Android Music Playback
Yes (via Bluetooth®)
iPod/iPhone Control
CarPlay[3]
Yes (via USB)
Mirroring for iPhone
Yes (via USB) *Need mirroring App
iPhone Music Playback
Yes (via USB or Bluetooth®)
USB
USB Port
x 1 (High Speed)
Position
Rear
USB Power Supply
Yes (2.1A High Current Charging)
Radio Tuner
Radio Broadcast Data System (RBDS)
Yes
Preset Stations
36(FM:24ch, AM:12ch)
Auto Memory Entry
Yes
FM
Frequency Range
87.9 - 107.9MHz
AM
Frequency Range
530-1,700kHz
Audio
Maximum Power Output (Front & Rear)
50Wx4
Full Bandwidth Power (Front & Rear)
22W x 4
EQ
Yes (13-Band Graphic EQ)
Preset EQ
Yes (7Preset + 3user)
Bass Boost
Yes
High-Pass Filter/Low-Pass Filter
Yes/Yes
Speaker Size Control
Yes
Inputs and Outputs
Video Out
x 1 (V:RCA)
Rear view camera Input
Yes
Line Output Terminals
2Preouts + Sub WF (Mono)
Pre-output Level/Impedance
2.5V / 10k ohms
Subwoofer Output with Level/Frequency Control
Yes (Normal / Reverse)
General
Back Up Memory
Yes
Short Chassis
Yes
Wireless Remote Control
Optional (RM-RK259 required)
Steering Remote Control Ready
Yes
Dimensions (W x H x D)
Installation Size
7-1/16" x 3-15/16" x 3-3/8" (178 x 100 x 86 mm)
Weight
2.41 lbs. (1.07kg) Including Trim plate
Unit weight in individual package
1.62kg
