Give your system dedicated amplifier power
The Pioneer GMA6704 4-Channel Bridgeable Amplifier with Bass Boost gives you four channels of amplification for a multi-speaker system. Match its output at your chosen impedance to the speakers you plan to run.
Key details
- Model / SKU: GMA 6704
- 60 watts RMS x 4 at 4 ohms (95 watts RMS x 4 at 2 ohms)
- 190 watts RMS x 2 in bridged mode (4-ohm stable in bridged mode)
Fitment & system matching
Match RMS output at the final wired impedance to your speakers or subwoofers. Check minimum impedance, mounting dimensions, fuse requirements and power-wire size. Peak/MAX ratings are not continuous RMS output.
Full product details & specifications
- 4-channel car amplifier
- 1000W Max power
- 60 watts RMS x 4 at 4 ohms (95 watts RMS x 4 at 2 ohms)
- 190 watts RMS x 2 in bridged mode (4-ohm stable in bridged mode)
- CEA-2006 compliant
- variable high- and low-pass filters (40-500 Hz, 12 dB per octave) on A channels
- switchable high- and low-pass filters (80 Hz, 12 dB/octave) on B channels
- bass boost (0-12 dB at 50 Hz) on B channels
- fuse rating: 25A x 2
- preamp and speaker-level inputs
- 8-gauge power and ground leads recommended — wiring and hardware not included with amplifier
- 14-1/16"W x 2-3/8"H x 8-1/2"D
